THE
TRAXIS DBS3500
UNLEASH
THE POWER OF BLIND SCAN &
Start finding New Channels, Wildfeeds & Backhauls of
Sports and News!
ONLY $ 105.00 plus 10.00 Shipping
in the Cont. 48 United States
Add a C/Ku Band Slave Kit for just
$28.00
Slave Kit includes: 2 - PV23402 2 Way HF 1 Port Passive
Splitters, 2 Way DiSEqC Switch
and 5 - 4' RG 6 Coax Cables
| FEATURES:
|
|
| *
Blind Search |
| *
Fully MPEG2 DVB Compliant |
| * Free
converting between PAL source and NTSC display |
| * User
programmable various satellite and transponder
information |
| *
Stores up to 100 satellites/4,000 channels |
| * EPG:
Display of title and information up to 16 days
events |
| * Easy
and fast software upgrade through RS232 port |
| *
Multi LNBF control by DiSEqC 1.0/1.2 and 0/22KHz
switching |
| *
SCPC/MCPC receivable from C and Ku band
satellites |
| *
Multi-language: English, German, French, Spanish,
Italian, Polish, Portuguese, Turkish |
| * Users Manual |
| LNB
TUNER INPUT |
| Connector |
| If Input |
F type
female |
| Loop Thru |
F type
female |
|
| Impedance |
75
Ohms |
| Input
Frequency |
950
- 2150 MHz |
| Input
Signal Level |
-25dBm
to -65 dBm |
| IF
Frequency |
Zero
IF |
LNB
Power & Polarization
Overload Protected |
| V=13 VDC |
12.5 - 14
VDC |
| H=18 VDC |
18 - 19.5
VDC |
|
| LNB
Power off |
1
VDC Max. |
| 22
KHz Tone |
| Impedance |
500 ohms |
| Frequency |
22Khz+/-4KHz |
| Amplitude |
0.65+/-0.25Vp-p |
| Rise Time |
10us |
| Duty Cycle |
50% |
|
| DiSEqC |
1.0/1.1/1.2 |
| VIDEO
OUTPUT |
| Connector
TV |
RCA
Jack (yellow) |
| Output
Impedance |
75
ohms |
| Output
Level |
1.0Vp-p |
| Video
Polarity |
Normal/Invert |
| Frequency
Response |
30Hz
to 5 MHz |
| AUDIO
OUTPUT |
| Connector
TV |
RCA
Jack (L white/R red) |
| Output
Impedance |
600
ohms |
| Output
Level |
2.5Vp-p |
| Frequency
Response |
50Hz
to 15 KHz |
| Volume
Control |
32
step |
| AC-3
COAXIAL OUTPUT |
| Connector |
RCA
(black) |
| Impedance |
75
ohms |
| Output
Level |
2.5Vp-p |
| Digital
Optical SPDIF Output |
2.5Vp-p |
|
| MODULATOR |
| Output
Video Carrier |
CH
3 (61.25 MHz)
CH 4 (67.25 MHz) |
| Video
Carrier Level |
67dBuV |
| Sound
Carrier Level |
16dB |
| Output
Impedance |
75
ohm |
| Sound
Carrier Frequency |
4.50
MHz |
| RS-232
Low speed serial data |
| Connector |
9-pin
D-sub |
| Signals |
RS232,
Max: 115.2 K bit/s |
| FRONT
PANEL |
| Display |
4x7
Segment LED |
| Buttons |
Power
On/Off
CH up
CH down |
| GENERAL
DATA |
| Supply
Voltage |
AC
90V to 264V
50 to 60 Hz |
| Power
Consumption Max. |
15W |
| Power
Consumption in Standby |
less
than 3W |
| Working
Temperature |
+5°C
to +40°C |
| Storage
Temperature |
-20°C
to +65°C |
| Remote
Operating Distance |
8
meter Min. |
| Remote
angle |
+/-25
Degree Min. |
| Environmental |
| Temperature |
0°C
to +40°C |
| Humidity |
40
RH to 90 RH |
| Mechanical
Specifications |
| Dimensions |
280x210x68mm |
|
THE
TRAXIS DBS3500
UNLEASH
THE POWER OF BLIND SCAN
& Start finding New Channels, Wildfeeds &
Backhauls of Sports and News!
ONLY $ 105.00 plus 10.00
Shipping in the Cont. 48 United States
Add a C/Ku Band Slave Kit for
just $28.00
Slave Kit includes: 2 - PV23402 2 Way HF 1 Port
Passive Splitters, 2 Way DiSEqC Switch
and 5 - 4' RG 6 Coax Cables
|
