FEATURES

TECHNICAL SPECIFICATIONS

• Fully MPEG-2 & DVB Compliant
• Input Frequency 950-2150MHz
• 200 MHz Connexant Processor
• 32 Mb SD RAM
• Supports 7 Day EPG (Electronic Program Guide)
• Supports PIG (Picture in Graphic)
• Supports SCPC & MCPC from C / Ku-band
• 1 LNB Input Tuner with Loop Through IF Signal
• Tuner Symbol Rate: 1-45MS/s
• New Universal Remote Control
• Card Reader (X Crypt Conditional Access System)
• Fast Booting & Auto Scan
• Hardware Driven Blindscan
• 4000 Channel Programmable (TV & Radio
• Fast Channel Changing
• User Friendly 256 Colors OSD & Easy GUI
• Multi OSD Language supported
• Radio Channel Screen Saver
• Favorite Channel List Programmable
• Master PIN Code Function & Parental Lock Function
• 100 Step Volume Control
• Automatic Detection of Forward Error Correction
• USB Host Interface (Only for USB Memory Stick)
• S/W Upgrade Supported by USB Port
• Window Based S/W Download Program Supported by RS232 Serial Port
• Set to Set Download (Main Program, Channel Data)
• 4:3, 16:9 Letter Box & Teletext using OSD
• 7 Segment-4 Digit Display
• 5 Keys on Front Panel
• (Power On/Off, Channel Up/Down, Volume Up/Down)
• Various LNB Polarity Control
• 22 KHz Switching Control
• Optical Output for Digital Audio
• S-VIDEO Output
• 3 RCA outputs (2 Audio L/R and 1 Video)
• 3 RCA Video Component Outputs (RGB
• RF-Modulator Output
• Rear Power Switch

Power Supply
Type: SMPS
Input Voltage: AC 95V~240v 50Hz / 60Hz
Fuse Rating: 250V/T2A

Tuner
Input Frequency: 950 ~ 2150MHz
Input Signal Level: -65 ~ -25dBm
Input Impedance: 75ohm Unbalanced
Connector Type: ‘F’Type Female
LNB Power Supply: 13V/18V, Max 500mA with Short Circuit Protection
22KHz Tone: Frequency 22± 4KHz, Amplitude 0.6±0.2Vpp
DiSEqC: 1.0 , 1.1, 1.2, USALS(1.3) Compatible
Channel Selection: PLL Frequency Synthesizer

Demodulator
Type: QPSK Demodulation (DVB-S)
Symbol Rate: 1 ~ 45 MS/s
Inner FEC: Viterbi Convolutional Coding
Rate 1/2, 2/3, 3/4, 5/6, 7/8
Outer FEC: Reed Solomon Coding(204,188) T=8

Video Decoder
System Decoding: MPEG-2 ISO/IEC 13818-2
Profile and Level: MPEG-2 MP@ML
Data Rate: 1 ~15 MB/s
Video Formats: 4:3(Normal) & 16:9(Widescreen)

Audio Decoder
System Decoding: MPEG-1 ISO/IEC 11172-3 Layer I & II
Audio Mode: Mono, Dual, Stereo, Joint Stereo
Sampling Frequency: 32, 44.1, 48 KHz

Audio/Video Output
Audio Output: 2 RCA Cinch (1 on LIte Model)
Video Output: 2 RCA Cinch (1 on Lite Model)
Digital Audio: 1 S/PDIF Optical (Platinum & Xtreme)
S-Video: 1 S-VIDEO
COMPONENT: 3 RCA Cinch (Xtreme)

RF Modulator
Modulator Output: CH3~4
Video Type: NTSC
Output Connector: “F” Type Female
Ant. IN Connector: “F” Type Female
8. Serial Data Interface
Signal: RS-232, Max. 115200 bps
Connector Type: 9 Pin D-Sub (male)
